SS TEE

Pipe tees, sorted as per reduced and equal types, provide the solution of bypass flow from the main direction by using the outlet branches. The size difference between the branch outlet and the main outlet leads to two basic types: equal (or so called "straight") type and reduced.

A) Size: 1/ 2”-48”, DN15-DN1200

B) Standard:

1) ANSI: ASME B16.9, ASME B16.28, MSS-SP-75,

2) DIN: DIN 2615
3) EN: EN 10253-1 EN 10253-2

C) Material:

1) Carbon Steel: ASTM A234 WPB, WPC

2) Stainless Steel: ASTM A403 WP304/ 304L, WP316/ 316L

D) Surface treatment: Transparent oil, rust-proof black oil or hot-dipped galvanizing
